S85D Diesel Stationary Air Compressor

OVERVIEW：

Zhigao brand S85D diesel engine screw air compressor is used to power pneumatic tool and machines such as pneumatic breaker, jack hammer, drilling machine, oil cleaning machine, sandblasting machine, drilling rig and so on.

Price:22,000-24,000USD

We're here to help:

Easy ways to get the answers you need.

Leave Message

FEATURES

1,Greater fuel efficiency and energy saving;
2,Air filtration system with vacuum indication for dust environments;
3,Compressor oil and engine coolant coolers to optimize performance and extend engine life;
4,Efficient compressor oil filter;
5,Fuel filter with water separator;
6,Easy to remove, translucent PE fuel tank.

TECHNICAL DATA

Technical Parameters of S85D Screw Air Compressor
Type	S85D
Name designation	Diesel screw air compressor
Nominal displacement	24m³/min
Rated discharge pressure	22bar
Maintain oil change rate	85L
Compressed series	1 Step
Engine type	YC6L310-H300 YUCHAI
Engine output	228kw
Fuel tank capacity	380L
Dimensions	356018302050mm
Total weight	3560kg
Air evacuation valve	G1-1/2 inch
